G-energy B0505LS-1WR3 5V To 5V 200mA 1W DC DC Converter IP68 Buck Boost Converter

Overview of this B0505LS-1WR3  5V To 5V 200mA 1W dc dc  converter

Introducing the G-energy B0505LS-1WR3 an smooth 5V to 5V 200mA 1W dc-dc converter at best price in India. This converter take 4.5v-5.5v dc input voltage and provide a fix 5v dc output with 200mA dc current and 1W max dc power. This G-energy B0505LS-1WR3 is a 5V to 5V 1W 200mA isolated dc-dc converter & give a compact and smooth power solution.

Features

Isolation Voltage (1500V DC): It also give high electrical isolation between input and output & protect sensitive circuit from voltage spike or noise.

Input voltage: This B0505LS-1WR3 converter take fluctuating 5V(4.5-5.5V) dc input and convert it to a fix 5v dc output.

Stable Performance: It maintain stable output voltage even if the input voltage varies within its working range.

Specification

1. Input Voltage Range: 4.5-5.5V

2. Output Voltage: 5V

3. Output Power: 1W

4. Output Current: 200mA

5. Isolation Voltage: 1500VDC

6. Efficiency: Up to 89%

7. Operating Temperature Range: -40℃ to +85℃

8. Package: SIP – Single Inline Package for compact design.

9. Over voltage Protection: Yes

10. Short Circuit Protection: Yes

🌡 Environmental Specifications

11. Operating Temperature Range: -40°C to +80°C

12. Storage Temperature Range: -40°C to +100°C

13. Humidity Range: 10% to 90% RH

🛡 Protections and Features

14. Waterproof Rating: IP68

15. Protections Included:

    • Short Circuit

    • Over current

    • Under voltage

    • Over temperature

    • Under voltage recovery

📦 Mechanical & Physical

16. Dimensions: 19mm × 10mm × 5mm

17. Weight: 3 gm

18. Cooling Method: Free air convection (no fan required)
