G-energy GEMSD480540A 48V To 5V 40A 200W Dc Dc Converter

Overview of this GEMSD480540A 48v to 5v 40a 200w dc dc converter

Introducing G-energy GEMSD480540A 48v to 5v 40a 200w dc dc converter at best price in India with G-energy. This voltage converter is built with 30v to 60v input voltage range & convert it to a fix 5v dc output voltage. It also provide high dc current up to 40A 200W max dc power to operate any dc industrial device.

Features

Input voltage: It is built with 30v to 60v dc input voltage for its compatibility with multiple dc set up.

Fix 5v dc output: It also provide a fix 5v dc output voltage to operate any smooth industrial operation running on 5v.

200W high power: This 48v to 5v buck converter also provide high dc power up to 200w and 40a max dc current.

Specification

Input Voltage: DC 30–60V

Output Voltage: DC 5V

Output Current: 40A

Output Power: 200W

Conversion Efficiency: Up to 94%

Operating Temperature: -40°C to +85°C

Protection Features: Over-current, over-voltage, over-temperature, short circuit

Cooling Method: Natural cooling

IP Rating: IP68 (dustproof and waterproof)

Input Terminal: Red(+) Black(-)

Output Terminal: Red(+) Black(-)

Dimensions: 124X104X51 mm

Mounting: Mounting holes for secure installation

Weight: 550g
