G-energy GEMSDS482460 48V To 24V 60A 1440W Dc To Dc Converter Ip68 Buck Converter

Overview of this 48v to 24v 60a 1440w dc to dc converter

Introducing g-energy 48v to 24v 60a 1440w dc to dc converter ip68 water proof step down converter. This voltage converter also come with wide input voltage of 30v to 60v for its smooth use at multiple input source. It also provide high dc power up to 1440w with 60a dc current for high power dc devices.

Features

Input voltage: This 48v to 24v converter also come with big input voltage of 30v to 60v and can smoothly work on multiple standard voltages of 36v 48v 60v.

1440w high power: It also provide high dc current up to 60a and maximum power up to 1440w dc power.

3 Month warranty: It also come with 3 month exchange warranty for quality assurance & you can claim for exchange against any defect in this time period.

Specification

🔧 Electrical Specifications

1. Input Voltage Range: 30V – 60V DC

2. Rated Input Voltage: 36V 48V 60V DC

3. Output Voltage: 24V DC

4. Maximum Output Current: 60A

5. Maximum Output Power: 1440W

6. Efficiency (Typical): Up to 98.1%

7. Voltage Regulation: ±1%

8. Load Regulation: 2%

9. Ripple & Noise: 300mV (at full load)

10. No-load Current Draw: 50mA @ 48V input

🌡 Environmental Specifications

11. Operating Temperature Range: -40°C to +80°C

12. Storage Temperature Range: -40°C to +100°C

13. Humidity Range: 10% to 90% RH

🛡 Protections and Features

14. Waterproof Rating: IP67

15. Protections Included:

    • Short Circuit

    • Over current

    • Over voltage

    • Over temperature

    • Under voltage recovery

16. Smart Chip Protection: Yes

17. Synchronous Rectification Technology: Yes

18. Non-Isolated Converter: Yes

📦 Mechanical & Physical

19. Dimensions: 100x80x36 mm

20. Weight: 600 gm

21. Cooling Method: Free air convection (no fan required)

Datasheet of GEMSDS482460 48v to 24v 60a dc voltage converter
