G-energy GEMSD724806 60V 72V To 48V 6A 288W Dc To Dc Converter Metal Body Ip68 Buck Converter

Overview of this 60v 72v to 48v 6a 288w dc to dc converter

Introducing G-energy 60v 72v to 48v 6a 288w dc to dc converter with aluminum metal body and ip68 water proof protection at best price in India with G-energy. This dc voltage converter can smoothly work on a big range of dc voltage from 52v to 90v dc input. And it also provide a fix 48v dc output with up to 6a dc current and 288w high power.

Features

High conversion efficiency: This 72v to 48v dc dc buck converter can provide high voltage conversion efficiency upto 95% conversion rate.

Metal body with ip68 protection: This dc dc converter is built with ip68 waterproofing protection for its safety from water.

High quality wires: This converter is built with high quality input and output wires which can handle up to 600W high power.

Specification

Input Voltage Range: 52V – 90V DC

Output Voltage: 48V DC

Output Current: 6A

Output Power: 288W

Conversion Efficiency: Up to 95%

Ripple and Noise: ≤ 100mV

Start-up Time: ≤ 1 second

Cooling Method: Natural Air Cooling

Protection Rating: IP68 (Waterproof and Dustproof)

Input Reverse Polarity Protection: Yes

Operating Temperature: -40°C to +80°C

Housing Material: Aluminum Alloy

Dimensions: Approx. 85mm x 52mm x 30mm

Weight: Approx. 250g
