G-energy GEMSUS122440 12V To 24V 40A 960W Dc To Dc Converter

Overview of this 12V to 24V 40A 960w Dc To Dc Converter

Introducing G-energy 12v to 24v 40a 960w dc dc converter at best price in India with G-energy. This high quality voltage boost converter is built with high quality aluminium body and screw terminal wire connection for easy wire connection. It also provide maximum current up to 40a and power up to 960w high power.

Features

Screw terminal wire connection: This dc converter come with screw terminal wire connection method for easy and safe wire connection for industrial use.

High quality built: This converter is built while maintaining its high quality body for rough and tough use at any harsh industrial connection.

Safety features: It also come with over current, and over heat protection for its safety while using in different industrial connection.

Specification

• Input Voltage Range: 10–20V

• Output Voltage Range: DC 24V ±1%

• Output Current: Up to 40A

• Output Power: Up to 960W

• Conversion Type: Non-Isolated Boost Converter

• Efficiency: Typically 90% or higher

• Ripple & Noise: ≤ 150 mV (peak-to-peak)

• Overcurrent Protection: Yes, with automatic recovery

• Thermal Protection: Yes, with thermal shutdown

• Operating Temperature Range: -40°C to +85°C

• Mounting Type: Screw holes for secure mounting

• Dimensions: 254 × 100 × 63.5 mm

• Weight: 2275 g
