G-energy GEPSD481203 24V 48V To 12V 3A 36W Dc To Dc Converter Ip68 Buck Converter

Overview of this 24v 48v to 12v 3a 36w dc to dc converter

Introducing G-energy dc 24v 48v to 12v 3a 36w dc to dc converter at best price in India with G-energy. This dc voltage converter can easily work on a wide dc input voltage range from dc 15v to 50v and convert it to a stable 12v dc output voltage. And it is built with abs plastic body with ip68 rated water proofing for converter use in wet industrial conditions.

Features

Ip68 rated water proofing: This dc dc converter is designed with ip68 rated waterproof body for converter safety from water.

Wide input voltage: This dc dc converter can easily work on a wide input voltage range from dc 15v to 50v input voltage range.

High efficiency: This converter is designed to provide a high conversion efficiency up to 91% conversion efficiency.

Specification

Input Voltage Range: 15V to 50V DC

Output Voltage: Fixed 12V ±2%

Output Current: 3A Maximum

Output Power: 36W Maximum

Efficiency: Up to 95%

Ripple and Noise: < 50mV (peak-to-peak)

Load Regulation: < 1%

Line Regulation: < 0.5%

Output Adjustment: Fixed 12V

Protection Features: Overload, Over-temperature, Short Circuit, Under voltage range

Input Overvoltage Protection: Yes

Output Overvoltage Protection: Yes

IP Rating: IP68 (Waterproof and Dustproof)

Cooling Method: Natural convection (passive cooling)

Operating Temperature Range: -40°C to +85°C

Storage Temperature Range: -40°C to +125°C

Housing Material: Aluminum Alloy

Mounting Type: Surface Mount

Certifications: CE, RoHS

Dimensions: 63.5 × 32 × 18 mm

Weight: 44g
