G-energy GEMSDF721230 72V To 12V 30A 360W Dc To Dc Converter With Fuse

Overview of this 72v to 12v 30a 360w dc to dc converter

Introducing G-energy 72v to 12v 30a 360w dc to dc converter with fuse at best price in India with G-energy. This 72v to 12v buck converter also come with additional fuse for its safety from over voltage or sudden voltage spikes. This voltage converter is built with high quality metal body for its rough and tough use in industrial setups.

Features

Over voltage protection: This 72v to 12v dc dc converter also come with additional replaceable fuse for its over voltage protection. In case if input dc voltage go above its input voltage range then circuit get closed and provide safety to converter and connected circuit.

High conversion efficiency: It is built with synchronous rectification technology and this advance technology provide maximum current up to 95% voltage conversion.

Die cast aluminum housing: This dc converter is built with aluminium cast outer body for its strong built quality.

Specification

• Input Voltage Range: 60V–80V

• Output Voltage: DC 12V

• Output Current: 30A

• Output Power: 360W

• Conversion Efficiency: Up to 95%

• Cooling Method: Passive (No fan required)

• Material: Die-cast aluminum housing

• Operating Temperature: -40°C to +80°C

• Short Circuit Protection: Yes

• Overload Protection: Yes

• Over-temperature Protection: Yes

• Input Reverse Polarity Protection: Yes

• Wiring Method:

  • Input: Screw(+), Screw(–)

  • Output: Screw(+), Screw(–)

• Dimensions: 112 × 115 × 35 mm

• Weight: Approx. 1.2 kg
