G-energy B1212S-1WR3 12V to 12V 83mA 1W Dc Dc Converter IP68 Buck Boost Converter

Overview of this G-energy B1212S-1WR3 12V to 12V 83mA 1W Dc Dc Converter IP68 Buck Boost Converter

Introducing  B1212S-1WR3 12V to 12V 83mA 1W dc dc converter at best price in India with g-energy. This 12v 12v buck boost converter provide up to 1 watt of power with 83mA dc current. This converter has built-in safety such as short circuit protection and over-current protection. This buck boost converter give up to 88% efficiency and convert power with minimal loss & reduce heat and saving energy.

Features

Input voltage: This voltage converter is built to smoothly work on 10.8v to 13.2v dc input voltage for its smooth operation.

Comes in SIP package: Converter comes in single Inline Package it is design for compact size and easy mounting on circuit board.

Over current & Short circuit protection: This buck boost converter automatically cuts off power during overload or short circuit to prevent damage to the converter and connected devices.

Specification

1.Input Voltage Range: 10.8-13.2V

2. Output Voltage: 12V DC

3. Output Current: 83mA

4. Output Power: 1W

5. Efficiency: 88%

6. Isolation Voltage: 1500V DC

7. Line Regulation: ±0.2% (Max)

8. Load Regulation: ±0.5% (Max)

9. Ripple and Noise: 50

10. Nominal Input Voltage: 12V

🌡 Environmental Specifications

11. Operating Temperature Range: -40°C to +80°C

12. Storage Temperature Range: -40°C to +100°C

13. Humidity Range: 10% to 90% RH

🛡 Protections and Features

14. Waterproof Rating: IP68

15. Protections Included:

    • Short Circuit

    • Over current

    • Under voltage

    • Over temperature

    • Under voltage recovery

📦 Mechanical & Physical

16. Dimensions: 11mm × 10mm × 5mm

17. Weight: 2 gm

18. Cooling Method: Free air convection (no fan required)
