G-energy WRB1212S-3WR2 12V To 12V 3W 250mA Dc Dc Converter IP68 Buck Boost Converter

Overview of this WRB1212S-3WR2 12V To 12V 3W 250mA dc dc converter

Introducing WRB1212S-3WR2 12V To 12V 3W 250mA dc dc converter IP68 buck boost converter at the best price in India with g-energy. This buck boost converter takes 9-18V input voltage range and convert it to a fix 12V output. It can deliver up to 3 watt dc power with 250mA maximum dc current for small electronic circuits, sensors, and control modules.  This converter comes in a standard single In-line package for easy mounting on PCBs, and ideal for easy integration into electronic circuit.

Features

Isolation Voltage: This WRB1212S-3WR2 12V To 12V 3W 250mA dc dc converter stand out with a1500VDC isolation voltage.

Compact Design: This WRB1212S-3WR2 compact design make it perfect solution for application with limited space provide versatility in installation.

2W Output Power – Converter can provide up to 2watt power with 250a dc current and make it perfect for small electronics, sensors, and control circuits.

Specification

1.Input Voltage Range: 9-18V

2. Output Voltage: 12V DC

3. Output Current: 250mA

4. Output Power: 3W

5. Efficiency: 85%

6. Isolation Voltage: 1500V DC

7. Line Regulation: ±0.2% (Max)

8. Load Regulation: ±0.5% (Max)

9. Ripple and Noise: 50

10. Nominal Input Voltage: 12V

🌡 Environmental Specifications

11. Operating Temperature Range: -40°C to +80°C

12. Storage Temperature Range: -40°C to +100°C

13. Humidity Range: 10% to 90% RH

🛡 Protections and Features

14. Waterproof Rating: IP68

15. Protections Included:

    • Short Circuit

    • Over current

    • Under voltage

    • Over temperature

    • Under voltage recovery

📦 Mechanical & Physical

16. Dimensions: 21mm × 11mm × 9mm

17. Weight: 5 gm

18. Cooling Method: Free air convection (no fan required)
