G-energy URB2412YMD-10WR3 24V To 12V 833mA 10W Dc Dc Converter

Overview of this URB2412YMD-10WR3 24V To 12V 833mA 10W Dc Dc Converter

Introducing G-energy URB2412YMD-10WR3 24v to 12v 833mA 10w dc dc converter at best price in India with G-energy. This dc buck converter work on input voltage range from 9v to 36v dc input voltage and provide a fix 12V dc output. It also provide up to 10w dc power for low power dc devices.

Features

Wide input voltage: It work on input voltage of 9v to 36v dc input voltage for both buck boost voltage conversion.

12V fix output: It also provide a fix 12v dc output voltage and for stable smooth operation.

Dip mount: it is built with dip(dual in line package) mount of easy mounting on pcb and smooth operation.

Input Voltage Range: 9-36V

2. Output Voltage: 12V

3. Output Power: 10W

4. Output Current: 833mA

5. Transfer Efficiency: 91%

6. Conversion Type: Isolated Buck Converter

7. Operating Temperature Range: -20°C to 80°C

8. Input/Output Isolation: Isolated

9. Over voltage Protection: Yes

10. Short Circuit Protection: Yes

🌡 Environmental Specifications

11. Operating Temperature Range: -40°C to +80°C

12. Storage Temperature Range: -40°C to +100°C

13. Humidity Range: 10% to 90% RH

🛡 Protections and Features

14. Waterproof Rating: IP68

15. Protections Included:

    • Short Circuit

    • Over current

    • Under voltage

    • Over temperature

    • Under voltage recovery

📦 Mechanical & Physical

16. Dimensions: 25mm × 25mm × 11mm

17. Weight: 15 gm

18. Cooling Method: Free air convection (no fan required)
