G-energy GEAPSD720501 24V 72V To 12V 1A 12W Dc Dc Buck Converter IP68 Module

Overview of this 24V 72V To 12V 1A 12W Dc Dc Buck Converter IP68 Module

Introducing G-energy dc 24v 72v to 12v 1a 12w dc dc converter ip68 at best price in India. This voltage converter come with a wide input range of 18v to 80 that make it compatible with 12v 24v 36v 48v 60v 72v of standard input voltage. It also provide maximum dc current up to 1a and 12w dc power for smooth industrial operation.

Features

High quality built: It is built with high quality aluminum body with epoxy base for its long term smooth use.

Wide input voltage: This 24v 72v to 12v converter also come with input voltage of 18v to 72v dc input voltage.

12W power: It is also built to provide dc power up to 12W to provide power low power dc device.

Specification

🔧 Electrical Specifications

1. Input Voltage Range: 18-80V

2. Rated Input Voltage: 24V 36V 48V 60V 72V DC

3. Output Voltage: 12V DC

4. Maximum Output Current: 1A

5. Maximum Output Power: 12W

6. Efficiency (Typical): Up to 95.4%

7. Voltage Regulation: ±1%

8. Load Regulation: 2%

9. Ripple & Noise: 96mV (at full load)

10. No-load Current Draw: 30mA @ 60V/72V input

🌡 Environmental Specifications

11. Operating Temperature Range: -40°C to +80°C

12. Storage Temperature Range: -40°C to +100°C

13. Humidity Range: 10% to 90% RH

🛡 Protections and Features

14. Waterproof Rating: IP68

15. Protections Included:

    • Short Circuit

    • Over current


    • Over temperature

    • Under voltage recovery

16. Smart Chip Protection: Yes

17. Synchronous Rectification Technology: Yes

18. Non-Isolated Converter: Yes

📦 Mechanical & Physical

19. Dimensions: 44x24x19

20. Weight: 40 gm

21. Cooling Method: Free air convection (no fan required)
